1. Safety instructions
1. Follow the installation instructions.
2. Use the device
• as it is intended to be used
• in perfect working order
• having regard to safety and potential dangers.
3. Please note that the device is exclusively intended for the
applications specified in these installation instructions.
Any other use, or any use which goes beyond this, will be
deemed non-intended use.
4. Please note that any installation, commissioning,
maintenance and adjustment works may only be carried
out by authorised specialists.
5. Faults that could impair safety must be rectified
immediately.
2. Functional description
Spring loaded pressure reducing valves operate by means of
a force equalising system. The force of a diaphragm operates
against the force of an adjustment spring. If the outlet
pressure and therefore diaphragm force fall because medium
is drawn, the then greater force of the spring causes the valve
to open. The outlet pressure then increases until the forces
between the diaphragm and the spring are equal again.
The inlet pressure has no influence in either opening or
closing of the valve. Because of this, inlet pressure fluctuation
does not influence the outlet pressure, thus providing inlet
pressure balancing.
3. Application
4. Technical data
5. Scope of delivery
The Pressure reducing valve consists of:
•
Housing with double-sided pressure gauge connection G
1
/
4
"
• Connections (types A & B)
• Sealing plugs with seals
• Valve insert complete with diaphragm and valve seat
• Fine filter with 0.16 mm mesh
• Spring bonnet with adjustment knob and setting scale
• Filter bowl
• Adjustment spring
• Venturi nozzle
- D06F, D06F-LF, D06FH, D06FI - 1
1
/
4
" + 2"
- D06FN - 2"
• Pressure gauge not included (see accessories)
6. Options
Medium Water
Inlet pressure max. 16 bar with transparent filter bowl
max. 25 bar with brass filter bowl
max. 25 bar with stainless steel filter bowl
Outlet
pressure
• D06F 1.5-6.0 bar (preset to 3 bar)
• D06F-LF 1.5-6.0 bar (preset to 3 bar)
• D06FH 1.5-12.0 bar (preset to 5 bar)
• D06FN 0.5-2.0 bar (preset to 1.5 bar)
• D06FI 1.5-6.0 bar (preset to 3 bar)
Caution!
In areas with UV radiation and solvent vapours, the
brass filter bowl SM06T or the stainless steel filter bowl
SI06T must be used!
Installation position Horizontal and vertical installation possible
Operating
temperature
max. 40°C with transparent filter bowl
max. 70°C with brass filter bowl (max.
operating pressure 10 bar)
max. 70°C with stainless steel filter bowl
(max. operating pressure 10 bar)
Minimum pressure
gradient
• D06F 1.0 bar
• D06F-LF 1.0 bar
• D06FH 1.0 bar
• D06FN 0.5 bar
• D06FI 1.0 bar
Connection sizes
1
/
2
" - 2"
D06F-... A = External threaded nozzle on inlet and outlet
Transparent filter bowl to 40 °C
D06F-... B = External threaded nozzle on inlet and outlet
Brass filter bowl to 70 °C
(max. operating pressure 10 bar)
D06F-... E = External thread on inlet and outlet
Transparent filter bowl to 40 °C
D06F-LF... A = Lead-free version
External threaded nozzle on inlet and outlet
Transparent filter bowl to 40 °C
D06FH-... B = External threaded nozzle on inlet and outlet
Brass filter bowl to 70 °C
(max. operating pressure 10 bar)
D06FN-... B = External threaded nozzle on inlet and outlet
Brass filter bowl to 70 °C
(max. operating pressure 10 bar)
D06FI-... A = External threaded nozzle on inlet and outlet
Transparent filter bowl to 40 °C
D06FI-... B = Stainless steel version
External threaded nozzle on inlet and outlet
Stainless steel filter bowl to 70 °C
(max. operating pressure 10 bar)
D06FI-... E = Stainless steel version
External thread on inlet and outlet
Transparent filter bowl to 40 °C
