Introduction | 21
800-21358 - A - 10/2015
Camera Dimensions
This section displays the dimensions and main components/connectors of each
Performance Series IP camera.
HED1PR3/HED3PR3 Ball Cameras
Figure 1-1 HED1PR3/HED3PR3 Dimensions
Figure 1-2 HED1PR3/HED3PR3 Components
1. Lens
2. Camera module
3. Camera enclosure
4. LAN connector
5. 12 V DC connector
2
1
3
4
5
