52 | Performance Series IP Camera Software Configuration Guide
Zoom and Focus
Note This section only applies to HBD3PR2 and H4D3PRV2 motorized focus/zoom
cameras.
Figure 5-3 Motorized Zoom and Focus
Table 5-2 Zoom and Focus
Parameter Function
Zoom Adjust the focal length of the lens by clicking "+" to zoom in or "–" to
zoom out. Changing the Speed setting adjusts the length of a
single-click increment.
Note
After adjusting zoom, the lens will focus automatically.
Focus Adjust the definition of the image by clicking "+" to focus far or "–" to
focus near. Changing the Speed setting adjusts the length of a
single-click increment.
Auto Focus Click to adjust the focus automatically.
Restore All Click to reset the lens to 0 position.
Note
Reset the lens periodically if you are making a lot of zoom and
focus adjustments.
Refresh Refreshes the video image that is displayed.
