First Time Setup (cont'd)
16
If the IP address is not displayed, change the “Internet Connection Type” to Static and manually enter
the IP address from your router onto the keypad. Highlight each field and enter the required
information for Subnet Mask, Default Gateway, DNS Server and Port #; press GO.
To change the default port number (6280), press the field next to port number and enter a secondary
port number between 5000-65534. A pop-up window displays:
“Success Network Details Saved”
“Port number changed. Keypad is going to reset”
Tuxedo will reboot with the newly configured port number.
Press the Save icon; the IP information will automatically update.
At your PC, Smart Phone or Tablet browser, start your browser and enter the Tuxedo IP Address to access the Tuxedo
home screen. Refer to the Remote Access section for further details.
Setup a WLAN (Wi-Fi) Connection
Press the WIFI ON button. A pop-up window displays:
“This will switch off LAN Network, do you want to continue?” Yes or No.
Use the scroll bar to locate a network from the list of Wi-Fi Networks to connect to and highlight that
field.
Or, scroll to the bottom of the list and select Add Network. Highlight each field to enter the required
information for SSID, Security Mode, Passphrase/Shared Key, and Port #.
To change the default port number (6280), press the field next to port number and enter a secondary
port number between 5000-65534. A pop-up window displays:
“Success Network Details Saved”
“Port number changed. Keypad is going to reset”
A pop-up window displays the message:
“Settings saved.”
Select
OK
to save.
Press the Save icon. Pressing Save when changing the port number resets the keypad.
At your PC, Smart Phone or Tablet browser, start your browser and enter your IP Address. Refer to the
Remote Access section for further details.
If left inactive, Web connections disconnect after 10 minutes.
