Honeywell Voyager XP 1472g2D User Manual

Locked Link
If you link a scanner to a base using the Locked Link Mode,
other scanners are blocked from being linked if they are inad-
vertently placed into the base. If you do place a different scan-
ner into the base, it will charge the scanner, but the scanner will
not be linked.
To use a different scanner, you need to unlink the original scan-
ner by scanning the Unlink Scanner bar code.
Override Locked Scanner
If you need to replace a broken or lost scanner that is linked to a
base, scan the Override Locked Scanner bar code with a new
scanner, and place that scanner in the base. The locked link will
be overridden; the broken or lost scanner’s link with the base will
be removed, and the new scanner will be linked.
Unlinking the Scanner
If the base has a scanner linked to it, that scanner must be
unlinked before a new scanner can be linked. Once the previous
scanner is unlinked, it will no longer communicate with the
base. Scan the Unlink Scanner bar code to unlink a scanner.
Locked Link Mode
(Single Scanner)
Override Locked Scanner
Unlink Scanner

Honeywell Voyager XP 1472g2D Specifications

General

Connectivity	Bluetooth
Environmental Sealing	IP42
Operating Temperature	0°C to 50°C (32°F to 122°F)
Weight	210 g (7.4 oz)
Motion Tolerance	Up to 400 cm/s (157 in/s) for 13 mil UPC at optimal focus
Expected Duration of Operation	14 hours
Expected Charge Time	4.5 hours
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	0% to 95% relative humidity, non-condensing
Light Levels	0 to 100, 000 lux
Battery	Lithium-ion battery
Drop Specification	Designed to withstand 30 drops from 1.8 m (6 ft) to concrete
Decode Capabilities	Reads standard 1D, PDF, 2D
Number of Scans	Up to 50, 000 scans per charge
Scan Angle	Horizontal: 40°; Vertical: 30°
