CLEARING BLOCKAGES
Low suction or pick up may be due to a blockage
in the system. Refer to the following steps to check
for blockages, continuing with each step until the
blockage is found:
3.14 The flexible hose can be disconnected from
the vacuum cleaner by pressing the release
button on hose connector and pull out as shown.
Remove any blockages found then reconnect the
hose securely.
3.15 Plug cleaner in, turn on, and check hose end
for suction. Remove any obstructions.
3.16 Remove power nozzle from wand and attach
wand to hose. Check for suction and remove any
blockages.
3.17 Remove power nozzle from wand and turn
over to bottom. Unlock nozzle cover latches.
3.18 Turn power nozzle over to top and open
hinged nozzle cover to access brushroll.
3.19 Clean debris from brushroll.
3.14 3.15
3.16
11
Actual model may vary from images shown.
CAUTION
! !
To reduce the risk of personal injury, unplug
vacuum before servicing.
3.17
3.18 3.19
