16
1700 SERIES PRESSURE WASHER OPERATOR’S MANUAL
Hotsy 1700 • 97-6419 • Rev. 7/06
ITEM PART NO. DESCRIPTION QTY
1 Unloader, See Specifications Pages 20-21
Unloader, See Specifications Pages 20-21
921579 Unloader, PA 8GPM@3650 PSI,
VB8 W/Switch (Auto Start/Stop) 1
2 Pump, See Specifications Pages 20-21
3 Motor, See Specifications Pages 20-21
4 867372 Hose, 1/2" Push On 18"
5 Transformer, See Specifications Pages 20-21
6 Fuse, See Specifications Pages 20-21
7 Fuse, See Specifications Pages 20-21
8 Contactor, See Specifications Pages 20-21
9 Overload, See Specifications Pages 20-21
10 800005 Din Rail, 35mm 4"
(Time Delay Option) 6"
11 616009 Box, Plastic, 10" x 8" x 6" w/Lid
(All models except 1710) 1
220275 Box, Plastic, 8" x 8" x 4" w/Lid
(1710) 1
12 616008 Bracket, Support for Elec Box 1
13 876029 Strain Relief, LQ Tit (1710) 1
903086 Locknut, 1/2" Conduit (1710) 1
875473 Strain Relief, 3/4" LQ Tite
(1720, 1722, 1723, 1724, 1725,
1733, 1734, 1735, 1745, 1755) 1
903087 Locknut, 3/4" Conduit (1720,
1722, 1723, 1724, 1725, 1733,
1734, 1735, 1745, 1753, 1755) 1
6-05170 Strain Relief, 3/4" (1730, 1732,
1743, 1744, 1753, 1754) 1
903087 Locknut, 3/4" (1730, 1732,
1743, 1744, 1753, 1754) 1
6-051930 Connector, 1" (1740, 1742, 1750,
1752) 1
6-05182 Locknut, 1" (1740, 1742, 1750,
1752) 1
14 876029 Strain Relief, Strt, LQ Tite, Med 1
903086 Locknut, 1/2" Conduit 1
15 4-02047722 Hose, 3/8" x 22", 2 Wire, Pressure
Loop (1710, 1720, 1722, 1723,
1724, 1725, 1730, 1732, 1733,
1734, 1735, 1740, 1742, 1743,
1744, 1745) 1
707513 Hose, 3/8" x 25", 2 Wire Pressure
Loop (1750, 1752, 1753, 1754,
1755) 1
16 2-3008150 Pump Protector, 1/2" PTP, 190°
(1710, 1752, 1753, 1754, 1755) 1
ITEM PART NO. DESCRIPTION QTY
16 2-30081 Pump Protector, 3/8" 190° (all
except 1710, 1750) 1
17 661356 Elbow, 1/2" JIC, 3/8" Fem, 90° 1
18 661357 Elbow, 1/2" JIC, 3/8", 90° 1
19 703146 Nut, 3/8" ESNA (All Models
Except 1710) 4
703155 Nut, 5/16" ESNA (1710) 4
20 780562 Washer, 3/8", SAE, Flat ( All
Models Except 1710) 8
780452 Washer, 5/16" SAE Flat (1710) 8
21 877455 Nipple, 3/4" Pipe x 1/2" Pipe
(1750, 1752, 1753, 1754, 1755) 1
722774 Nipple, 1/2" Pipe x 3/8" Pipe
(1720, 1722, 1723, 1724,1725,
1730, 1732, 1733, 1734,1735,
1740, 1742, 1743, 1744,1745) 1
897952 Nipple, 1/2" Close (1710) 1
22 954710 Tee, 1/2" Female, Pipe 1
23 799419 Nipple, 1/2" JIC x 1/2" MPT Pipe 1
24 661355 Elbow, 1/2" JIC x 1/2", 90° 2
25 661357 Elbow, 1/2" JIC x 3/8" Steel (1710,
1720, 1722, 1723, 1724, 1725,
1730, 1732, 1733, 1734, 1735,
1740, 1742, 1743, 1744, 1745) 1
644600 Elbow, 1/2" JIC x 1/2", 90° (1750,
1752, 1753, 1754, 1755) 1
26 661354 Elbow, 1/2" x JIC x 3/8", Brass 1
27 722740 Bushing, 3/4" x 1/2" Pipe
(
1750, 1752, 1753, 1754, 1755
) 1
28 630040 Cover, Hotsy 1700 Series 1
29 630006 Base, Hotsy 1700 Series 1
30 875858 Switch, Rocker, Carling
w/Green Lens 1
876321 Switch, Rocker, Red Face
(Time Delay Only) 1
31 615527 Pad, Soft Rubber, 50 Duro 4
32 859815 Grommet, Rubber,
Nozzle Holder 4
33 801139 Swivel, 1/2" MP x 3/4"
GHF w/Strainer 1
34 631008 Connector, 1/2" Anchor 1
35 631007 Connector, 3/8" Anchor 1
36 729404 Downstream Injector Assy.,
Non Adj #3 1
37 844806 Nipple, 3/8" x 3/8" NPT ST Male 1
38 799000 Nozzle, SAQCMEG 0004 Red
(1730, 1732, 1733, 1734, 1735) 1
1700 SERIES -EXPLODED VIEW PARTS LIST
