1700 SERIES PRESSURE WASHER OPERATOR’S MANUAL
Hotsy 1700 • 97-6419 • Rev. 7/06
ITEM PART NO. DESCRIPTION QTY
60 903087  Locknut, 3/4" Conduit (1740,
1742, 1743, 1744, 1750, 1752,
1753, 1754) 1
61 646648 Label, Intended For Indoor Use 1
62 661357 Elbow, 1/2" JIC, 3/8", Steel (Auto
Start Option) 1
63 661354 Elbow, 1/2" JIC, 3/8", Brass (Auto
Start Option) 1
64 644802 Elbow, 3/8" Street (Auto Start
Option) 2
65 661426 Swivel, 1/2" JIC Fem x 3/8" Male
(Auto Start Option) 1
66 834083 Label, Hotsy, White 1
67 630007 Cover, Access Hole 1
68 444467 Label, Caution 1
69 646666 Label, Cold Water Inlet 1
70 780452 Washer, 5/16" Flat 4
71 90-1027461 Bolt, 1/2" x 8" NC HH 1
72 780455 Washer, 1/2" Flat 1
73 95-0710375546 Slider, Pump 1
74 703155 Nut, 5/16" ESNA 4
75 898111 Nipple, 1/2" JIC x 3/8" Female
(Auto Start Option) 1
76 815220 Bushing, 1/2" x 3/8" Steel (Auto
Start Option, 1750, 1752, 1753,
1754, 1755) 1
77 10-9999 Clear Lexan 1
78 834159 Detergent label 1
79 830587 Bumper Pad 4
80 630011 Weather Stripping 7 ft.
81 630008 Nut, 1/4" Square 4
82 2-1105 Swivel, 1/2" JIC Fem. Push-On 4
83 826009 Cord, 16-4 Service 2.5 ft.
84 799484 Nut, 10/32" Keps (1710) 4
(1723, 1724, 1725, 1733, 1734,
1735, 1744, 1745, 1754, 1755) 7
(1720, 1722, 1730, 1732, 1740,
1742, 1743, 1750, 1752, 1753) 10
85 612985 Bolt, 3/8" x 1-1/2" NC HH 4
86 876025 Screw, 10/32" x 1/2" Black (1723,
1724, 1725, 1733, 1734, 1735,
1744, 1745, 1754, 1755) 10
(1720, 1722, 1730, 1732, 1740,
1742, 1743, 1750, 1752, 1753) 11
87 876026 Screw, 10/32" x 1-1/4" (1710) 2
(Auto Start Option, All Models
Except 1710) 1
1700 SERIES - EXPLODED VIEW PARTS LIST (CON'T)
ITEM PART NO. DESCRIPTION QTY
88 703185 Nut, 1/4" ESNA NC 2
89 185300 Cage Nut, 10/32" x 16 Gauge
(1723, 1724, 1725, 1733, 1734,
1735,1744, 1745, 1754, 1755) 6
(1720, 1722, 1730, 1732, 1740,
1742, 1743, 1750, 1752, 1753) 4
90 799488 Cage Nut, 1/4" x 12 Gauge 8
91 936688 Washer, 3/8" x 1-1/2" Fender 4
92 646155 Label, Ground 2
93 95-07290068 Standoff, Electrical Box (All
Models Except 1710) 1
94 826043 Strain Relief, 3/4" (1710, 1720,
1722, 1723, 1724, 1725, 1734,
1735, 1740, 1742, 1750, 1752) 1
826029 Strain Relief, 1" (1730, 1732,1733,
1743, 1744, 1745, 1753, 1754,
1755) 1
95 891010 Timer, Solid State, 120V 5-60
Min. Adjust. (Auto Start Option) 1
96 876032 Strain Relief, 1/2" (Auto Start/
Time Delay Option) 1
903086  Locknut, 1/2" (Auto Start/Time
Delay Option) 1
97 829596 Plug, 3/8" Gas Tap (Time Delay
Option, 1720, 1722, 1723, 1724,
1725, 1730, 1732, 1733, 1734,
1735, 1740, 1742, 1743, 1744,
1745) 1
98 875651 Switch, Pressure Block (Time
Delay Option) 1
99 876320 Timer, Multi-Function (Time Delay
Option) 1
100 815220 Bushing, 1/2" x 3/8" Steel (Time
Delay Option, 1750, 1752, 1753,
1754, 1755) 1
101 644802 Elbow, 3/8" Street (Time Delay
Option, 1710, 1750, 1752, 1753,
1754, 1755) 1
102 703146 Nut, 3/8" ESNA NC 4
103 867372 Hose, 1/2" Push-on 12"
104 780453 Washer, 3/8" SAE Flat (All except
1710) 4
780452 Washer, 5/16" SAE Flat (1710) 4
105 1-96710600 Washer (All except 1710) 4
780479 Washer, 5/16" Lock, Split (1710) 4
106 726318 Bolt, Pump Mounting (All except
1710) 4
615532 Bolt, 8mm x 16mm Hex Head
(1710) 4
    Not Shown
