Hotsy 1710 User Manual

22
Exploded View Parts List
REF PART NO. QTY DESCRIPTION NOTES
52 9.802-283.0 1 HOUR METER
53 9.802-720.0 4 BOLT, 3/8” X 1", NC HH (ALL MODELS EXCEPT 1710)
- 9.802-710.0 4 BOLT, 5/16” X 1", NC HH (1710)
- 8.718-621.0 4 BOLT, 5/16” X 1" NC HH (1710 - SS OPTION)
- 9.802-721.0 4 BOLT, 3/8” X 1" SS (SS OPTION)
54 8.932-965.0 1 LABEL, WARNING, EXPOSED PULLEY
55 8.932-970.0 1 LABEL, COLD WATER OUTLET
56 9.802-429.0 10 ft. SERVICE CORD 12/4 (1723, 1724, 1725, 1745,1755)
- 9.802-426.0 10 ft. SERVICE CORD 8/4 (1743, 1744, 1753, 1754)
- 9.802-430.0 1 GFCI CORD 230V/30 AMP, 10-3 CORD (1720, 1722)
- 9.802-431.0 1 GFCI CORD 120V/20 AMP W/36', 12-3 CORD (ONLY 1710)
57 8.932-969.0 1 LABEL, GFCI
58 9.802-522.0 1 STRAIN RELIEF 1"
59 9.802-428.0 51” SERVICE CORD 12/3 (ONLY 1710)
- 9.802-429.0 40” SERVICE CORD 12/4 (1723,1724, 1725,1745, 1755)
- 9.802-436.0 40” SERVICE CORD 10/3 (1722,1720)
9.802-426.0 40” SERVICE CORD 8/4 (1743, 1744, (1753,1754)
60 9.802-518.0 1
STRAIN RELIEF, STRT, LQ TITE 3234 LARGE (1720, 1722,
1723, 1724, 1725, 1745, 1755)
- 9.802-526.0 1
LOCKNUT, 3/4” CONDUIT (1720,1722,1723,1724,1725, 1745,
1755)
NOT SHOWN
- 9.802-515.0 1 STRAIN RELIEF LQ TITE (ONLY 1710)
- 9.802-524.0 1 LOCKNUT, 1/2” CONDUIT (ONLY 1710) NOT SHOWN
- 9.802-521.0 1 STRAIN RELIEF, 3/4” (1743,1744, 1753, 1754)
- 9.802-526.0 1 LOCKNUT, 3/4” CONDUIT (
1743, 1744, 1753, 1754) NOT SHOWN
61 9.800-013.0 1 LABEL, INTENDED FOR INDOOR USE
62 9.802-039.0 2 ELBOW, 1/2” JIC, 3/8”, STEEL (AUTO/START OPTION)
63 9.802-129.0 1 ELBOW, 1/2” JIC, 3/8”, BRASS (AUTO/START OPTION)
64 8.706-207.0 1
ELBOW, 3/8” STREET
(AUTO START OPT) (1710, 1720, 1722,
1723, 1724, 1725, 1743, 1744,
1745)
- 8.706-171.0 1 ELBOW, 1/2” MPT X 3/8 MPT STREET (1753, 1754, 1755)
65 9.802-048.0 1 SWIVEL, 1/2” JIC FEM X 3/8" MALE (AUTO START OPTION)
66 8.903-108.0 1 LABEL, HOTSY, WHITE
67 8.912-147.0 1 COVER, ACCESS HOLE
68 9.800-016.0 1 LABEL, DISCONNECT POWER SUPPLY
69 9.800-020.0 1 LABEL, COLD WATER INLET
70 8.718-980.0 4 WASHER, 5/16” FLAT
- 9.802-805.0 4 WASHER, 5/16" FLAT (SS OPTION)
71 9.802-738.0 4 BOLT, 1/2” X 8" NC HH
- 9.802-739.0 1 BOLT, 1/2”-13 X 8" HEX, SS (SS OPTION)
72 9.802-800.0 1 WASHER, 1/2” FLAT
- 8.731-141.0 1 WASHER, 1/2” FLAT, (FOR SS OPTION)
Hotsy 1700 Operator’s Manual 8.914-380.0 - W
