Speakers
Description Spare part number
Speaker Kit, includes left and right speakers 678227-001
The speakers are located at the bottom of the computer. Two separate speakers are each secured by
two screws and have separate cables and system board connectors.
To remove the speakers:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 37).
2. Remove the rear cover (see
Rear Cover on page 38).
3. Disconnect the two speaker cables (1) from the system board.
Speakers 53
