Power connector cable (DC-in)
Table 6-13 Power connector cable description and part number
Description Spare part number
Power connector cable L22528-001
Before removing the power connector cable, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Remove the optical drive (see Optical drive on page 33).
3. Remove the bottom cover (see Bottom cover on page 37).
4. Remove the battery (see Battery on page 40).
Remove the power connector cable:
1. Remove the two Phillips M2.5 × 6.0 screws from the right display hinge (1), and then rotate the hinge up
from on top of the power connector (2).
2. Disconnect the power connector cable from the system board (3).
3. Remove the power connector cable from the computer (4).
Reverse this procedure to install the power connector cable.
Component replacement procedures 55
