Optical drive
NOTE: The optical drive spare part kit includes the rear optical drive bracket but does not include the
optical drive cable or cable bracket. The optical drive cable and cable bracket are included in the
optical drive cable kit. See
Optical drive cable on page 107 for more information about the optical
drive cable and cable bracket.
Description Spare part number
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 685096-001
Optical drive insert for use in models without an optical drive 702756-001
Before removing the optical drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 56).
5. Remove the memory module/wireless module compartment cover (see
WLAN module
on page 64).
6. Remove the hard drive (see
Hard drive on page 70).
To remove the optical drive:
1. Remove the Phillips PM2.5×4.0 screw (1) that secures the optical drive to the computer.
2. Insert a screwdriver or similar small tool into the hole at the rear of the optical drive bay, and then
push the optical drive (2) to release it from the bay.
74 Chapter 4 Removal and replacement procedures
