Speakers
Description Spare part number
Speakers (includes left and right speakers and cable) 685106-001
Before removing the speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 56), and then remove the following components:
●
Memory module/wireless module compartment cover (see
WLAN module on page 64)
●
Hard drive (see
Hard drive on page 70)
●
Keyboard (see
Keyboard on page 76)
●
Top cover (see
Top cover on page 79)
To remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. To release the left speaker (2) out from under the system board, rotate the left speaker (3) toward
the system board.
Component replacement procedures
87
