Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see
Display assembly components on page 14.
(2) Top cover/keyboard for use in India (includes touchpad and keyboard cable) 802473-D61
(3) TouchPad button board (includes TouchPad cable, TouchPad button board cable, and
double-sided adhesive)
802468-001
(4) Speaker Kit (includes left and right speakers and cables) 802477-001
(5) Power connector cable 802488-001
(6) System board equipped with an A4-PRO 3340B 2.20-GHz processor (quad core, 25 W, 2-MB
L2 cache) and the Windows 8 Professional operating system (includes replacement
thermal material)
802492-601
(7) Heat sink (includes replacement thermal material) 802480-001
(8) RTC battery 718440-001
(9) Fan (includes cable) 802479-001
(10) WLAN module:
Qualcomm Atheros AR9565 802.11b/g/n 1×1 WiFi + Bluetooth 4.0 Combo Adapter 675794-001
(11) Audio/USB board 802469-001
(12) Hard drive (does not include hard drive bracket or hard drive connector adapter):
NOTE: The hard drive bracket, rubber frame, and cable are included in the Hard Drive Hardware Kit, spare part number
802471-001. See
Mass storage devices on page 15 for more information on the Hard Drive Hardware Kit.
500-GB, 5400-rpm, SATA, 7.0-mm hard drive 778186-001
(13) Base enclosure 802470-001
(14) Li-ion battery
6-cell, 47-WHr, 2.20-AHr, Li-ion battery 796352-001
4-cell, 41-WHr, 2.80-AHr, Li-ion battery 752237-001
(15) Memory modules (DDR3L, 12800, 1600-MHz):
2 GB 691739-001
Plastics Kit, includes: 802476-001
(16) Memory cover
(17) Optical drive bay space saver
Computer major components 13
