Fan
Description Spare part number
Fan (includes cable) 802479-001
Before removing the fan, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 23).
5. Remove the memory cover (see
Memory cover on page 24).
6. Remove the bottom cover (see
Base enclosure on page 26).
Remove the fan:
1. Disconnect the fan cable from the system board (1).
2. Loosen the two Phillips screws (2) that secure the fan to the system board.
3. Remove the fan (3).
Reverse this procedure to install the fan.
34 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
