Main board- Connector repair (Audio, HDMI and
DisplayPort)
Repair Condition: Connector repair is only for the monitor that has been out
of warranty period.
• The repair procedure is for Audio, HDMI and DisplayPort connectors.
• The connectors are on the main board (IF board part number 5E.49201.011).
• Please refer to the location to repair the correct parts:
IMPORTANT:
• Repair Condition: Connector repair is only for out of warranty.
• Repairing must operate by professional repairers (Note) in repair center, not
applicable for end user.
• Electrostatic protection is required when component replacement is required.
• The monitor meets ROHS, please use Lead-free solder wire for soldering.
• If Connector need to replace, must check specification and part number whether
match the BOM and location.
• If connector need to replace, please insert new parts carefully because the near
pin may cause short circuit by inappropriate operate.
