Typical settings
Sleep
O
33.5 W
<0.5 W
<0.3 W
Input terminal One DisplayPort, one HDMI port
Preset display resolutions
The display resolutions listed below are the most commonly used modes and are set as factory defaults. This
monitor automatically recognizes these preset modes and they will appear properly sized and centered on the
screen.
Preset Pixel format Horz freq (kHz) Vert freq (Hz)
1 640 × 480 31.469 59.94
2 720 × 400 31.469 70.087
3 800 × 600 37.879 60.317
4 1024 × 768 48.363 60.004
5 1280 × 720 45 60
6 1280 × 800 49.702 59.81
7 1280 × 1024 63.981 60.02
8 1440 × 900 55.469 55.901
9 1600 × 900 60 60
10 1680 × 1050 65.29 59.954
11 1920 × 1080 67.5 60
Preset Timing name Pixel format Horz freq (kHz) Vert freq (Hz)
1 480p 720 × 480 31.469 60
2 576p 720 × 576 31.25 50
3 720p50 1280 × 720 37.5 50
4 720p60 1280 × 720 45 60
5 1080p60 1920 × 1080 67.5 60
6 1080p50 1920 × 1080 56.25 50
20 Appendix A Technical specications
