Output Frequency
As shown below, the output frequency range depends on the function
currently selected. The default frequency is 1 kHz for all functions.
For arbitrary waveforms that you create and download to memory,
the maximum frequency depends on the number of points specified in
the waveform. As shown below, the maximum output frequency
decreases as you specify more points in the waveform. The five built-in
arbitrary waveforms can be output at a maximum of 5 MHz.
Function
Sine
Square
Triangle
Ramp
Built-In Arbs
1
Minimum Frequency
100
µHz
100
µHz
100
µHz
100
µHz
100
µHz
Maximum Frequency
15 MHz
15 MHz
100 kHz
100 kHz
5 MHz
1 There are five built-in arbitrary waveforms stored in non-volatile memory:
sinc, negative ramp, exponential rise, exponential fall, and cardiac.
Number of Arb Points
8 to 8,192 (8k)
8,193 to 12,287 (12k)
12,288 to 16,000
Minimum Frequency
100
µHz
100
µHz
100
µHz
Maximum Frequency
5 MHz
2.5 MHz
200 kHz
3
Chapter 3 Features and Functions
Output Configuration
57

HP 33120A Specifications

General

Frequency Range	100 µHz to 15 MHz
Waveforms	Sine, Square, Triangle, Ramp, Arbitrary
Amplitude Range	10 mVpp to 10 Vpp into 50 Ohms
Output Impedance	50 Ohms
Interface	GPIB
Function Generator Type	Arbitrary
Power Requirements	100/120/220/240 VAC ±10%, 50/60 Hz, 60 VA max
