Service Kit
The spectrum analyzer service kit (HP part number 08562-60021) contains service tools
required to repair the instrument. Refer to Table l-2 for a list of items in the service kit.
Table l-2. Service Kit Contents
Description
Cable Puller
PC Board Prop
Line Filter Assembly
Line Switch Cable
Extender Cable
BNC to SMB (snap-on) Cable
Connector Extractor Tool Kit
I
I
Quantity
1
1
1
1
1
2
HP Part Number
5021-6773
5021-7459
5061-9032
5062-0728
5062-0737
85680-60093
8710-1791
Electrostatic Discharge
Electrostatic discharge (ESD)
can damage or destroy electronic components. Therefore,
all work performed on assemblies consisting of electronic components should be done at a
static-free workstation. Figure l-l is an example of a static-safe workstation using two kinds
of ESD protection:
w
Conductive table mat and wrist-strap combination
n Conductive floor mat and heel-strap combination
These methods may be used together or separately.
l-4 General Information
