HP 8562E Service Manual

9. Frequency Response Adjustment
BNC CABLE
f
SYNTHES I ZEO
FREQIJE
~ SWEEPER ISTANDI
:NCY
\RD EXT
RF
OUTPUT
ADAPTER
!I
RECE I VEi
i
A
I
REF
POWER
SPLITTER
ADAPTER
Figure 2-17. Frequency Response Adjustment Setup
Equipment
Synthesized sweeper
...........................................
HP 8340A/B
Measuring receiver
..............................................
HP 8902A
Power sensor
................................
..I
................
HP 8482A
Power sensor ...................................................
HP 8485A
Power splitter
..................................................
.HP 11667B
Adapters
Type N (m) to Type N (m)
........................................
1250-1475
Type N (m) to APC 3.5 (m)
.......................................
1250-1743
Type N (f) to APC 3.5 (m)
........................................
1250-1750
Type APC 3.5 (f) to APC 3.5 (f)
...................................
5061-5311
Cables
BNC,122cm (48in) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP 10503A
APC 3.5,91cm(36in) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...8120-4921
\
SK112
2-44 Adjustment Procedures
