Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(3a) Touchpad
NOTE: The touchpad spare part kit does not include the touchpad bracket or touchpad cable. The
touchpad bracket is available using spare part number L18300-001. The touchpad cable is included in
the Cable Kit, spare part number L14906-001.
L14922-001
(3b) Touchpad bracket L18300-001
(3c) Touchpad cable: (included in the Cable Kit, spare part number L14906-001)
(4) Speakers (include left and right speakers and cables) L14920-001
(5) Battery (2 cell, 47 Whr, 6.15 Ahr, Li) 917725-855
Battery shield (not illustrated) L95285-001
(6a) Connector board (includes HDMI port and USB port)
NOTE: The connector board spare part kit does not include the connector board cable. The connector
board cables are included in the Cable Kit, spare part number L14906-001.
L14923-001
(6b) I/O bracket L14359-001
(6c) Connector board low-power cable (included in the Cable Kit, spare part number L14906-001, includes double-sided adhesive)
(6c) Connector board high-power cable (included in the Cable Kit, spare part number L14906-001, includes double-sided adhesive)
Intel D1 7265 ac 2×2 + Bluetooth 4.2 LE M.2 2230 non-vPro PCI-e+USB WW with 2 antennas (not
illustrated)
860883-001
(7) System board equipped with an Intel Celeron N3350 1.1 GHz (SC Turbo up to 2.4 GHz) processor
(2400 MHz FSB, dual core, 2 MB L2 cache, 6W), 4 GB of system memory, and 32 GB of eMMC system
storage (includes a graphics subsystem with UMA memory, replacement thermal material, and the
Chrome operating system)
L15851-001
(8) Heat sink (includes replacement thermal material) 928840-001
Battery tape (not illustrated) L14905-001
(9) Base enclosure L49985-001
(29.6 mm) 11.6 in display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
ENWW (29.6 mm) 11.6 in display assembly subcomponents 13
