HP Chromebook 11a User Manual

8. Release the ZIF connector (4) to which the TouchPad cable is connected, and then disconnect the TouchPad
cable from the system board.
Reverse this procedure to install the top cover/keyboard.
Touchpad cable
To remove the touchpad cable, use this procedure and illustration.
NOTE: The touchpad cable is included in the Cable Kit, spare part number L14906-001.
Before removing the touchpad cable, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 29).
2. Remove the top cover/keyboard (see Top cover/keyboard on page 29).
Remove the touchpad cable:
1. Detach the TouchPad cable (1) from the keyboard/top cover. (The TouchPad cable is attached to the
keyboard/top cover with double-sided adhesive.)
30 Chapter 5 Removal and replacement procedures for authorized service provider parts ENWW

HP Chromebook 11a Specifications

General

Brand	HP
Model	Chromebook 11a
Category	Laptop
Language	English
