Rear Components
Figure 1-4 Rear Components
Table 1-3 Rear Components
Component Component
1 Drive access panel 7 Security lock slot
2 Center access panel 8 Power connector with LED indicator
3 Memory access panel 9 RJ-45 Gigabit Ethernet port
4 Optical drive location 10 Stereo audio line out
5 Hard drive location 11 (4) USB 2.0 ports
6 Memory location
Keyboard Features
Figure 1-5 Keyboard Features
4 Chapter 1 Product Features ENWW
