HP Compaq Elite 8300 Specification

1920 x 1440 85 N/A
2048 x 1536 75 N/A
2560 x 1600 N/A N/A
Note : 60-R denotes reduced blanking timings are used on single link DVI connections and may be sued with other digital connections.
AMD Radeon HD 7450 Graphics Card
Introduction
The AMD Radeon HD 7450 DP (1GB) PCIe x16 Graphics Card provides a low profile, PCI Express x16 graphics add-in card solution based
on the AMD Radeon™ HD 7450 Graphics Processor. This card supports dual displays with its DisplayPort and dual link (DL) DVI
connectors.
An ideal solution for desktop PC customers seeking stable 2D and advanced 3D graphics performance, the AMD Radeon HD 7450 DP
(1GB) PCIe x16 Graphics Card is an excellent choice for small business users engaging in Web conferencing or video or photo editing,
while improving the everyday business PC experience with better graphics and excellent visual display quality.
The AMD Radeon HD 7450 DP (1GB) PCIe x16 Graphics Cards delivers PCI Express (PCIe) features including:
Full 16 lane PCIe bus support with peak bandwidth support
High resolution monitor support with the dual-link DVI port
Multi-mode DisplayPort connector for current and future display technology support
NOTE: Discrete graphics adapters can also access and use shared system memory, aka non-local video memory, through the PCI
Express bus. Because system memory is accessed across the system bus, accessing it is much slower than accessing local memory.
Discrete graphics adapters generally share a portion of system memory with the CPU. Typically, these adapters do not ask for
dedicated use of system memory for graphics, thus leaving more resources available for the rest of the system.
Key Benefits
1GB of DDR3 dedicated on-board graphics frame buffer memory
Featuring the AMD Radeon™ HD 7450 Graphics Processing Unit
Conforms to full PCI Express 2.0A specification for low profile form factor (x16 lanes native PCI Express implementation)
Provides dual-link (DL) DVI-I and DisplayPort output ports. A DVI-to-VGA adapter cable included
DisplayPort connector supports multimode technology to support connection to DVI-D, VGA and HDMI monitors with optional
adapters in kits NR078AA , FH973AT , BP937AA , AS615AA .
For a DisplayPort to DisplayPort connection use the optional DisplayPort Cable Kit VN567AA
Supports audio with video through the DisplayPort connector
Multi-Stream DisplayPort support provided in a future driver update
HDCP supported on DisplayPort and DVI output
DirectX 11 support in hardware for optimal performance in DX11 applications.
ATI Avivo technology for improved image and video playback.
OpenGL 4.0 support in hardware for optimal performance with OpenGL applications
Thermally controlled fan for quiet operation.
Low Halogen construction
Form Factor
PCI Express x16 (generation 2.0)
Low Profile, half length, 2.3" x 6.6"
Full height bracket utilized when configured to CMT or MT
Graphics Controller
AMD HD 7450 GPU
(based on AMD Radeon HD 6000 series technology)
QuickSpecs
HP Compaq Elite 8300 Business PC
Technical Specifications - Graphics
DA - 14268 North America — Version 41 — November 22, 2013 Page 24

HP Compaq Elite 8300 Specifications

General

Operating temperature (T-T)	10 - 35 °C
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
HDD size	3.5 \
Dimensions (WxDxH)	178 x 445 x 448 mm
Microphone in	Yes
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
PCI slots	3
Chassis type	Mini-Tower
Product type	PC barebone
Product color	Gray
Audio system	HD
Motherboard chipset	Intel® Q77 Express
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Power supply	320 W
Operating system installed	No
Processor model	-
Processor family	Intel

Weight and Dimensions

Weight	11200 g
