HP Compaq Elite 8300 Specification

Intel® Core™ i3-2130 Processor
3.4 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 2000
Supports DDR3 memory up to 1333 MT/s data rate
X X
Intel® Core™ i3-2120 Processor
3.3 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 2000
Supports DDR3 memory up to 1333 MT/s data rate
X X
Intel® Pentium® Processors
Intel® Pentium® G870 Processor
3.1 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
X X
Intel® Pentium® G860 Processor
3.0 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
X X
Intel® Pentium® G640 Processor
2.8 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1066 MT/s data rate
X X
CHIPSET
USDT SFF/CMT
Intel® Q77 Express X X
GRAPHICS
USDT SFF/CMT
Integrated on all models (depends on processor)
Intel HD Graphics: Basic, 2000, 2500, 4000 X X
NOTE: When the USDT model configuration includes an Intel Core i5 or Intel Core i7 processor but not a discrete MXM graphics
card, all three monitor ports are driven by the processor's integrated graphics engine. When the model is configured with an Intel
Pentium or Core i3 processor only 2 of the 3 graphics display ports are active. Due to a limitation with the Intel integrated
graphics, when a DisplayPort to DVI or HDMI adapter is installed, the VGA port will not be active.
Optional Discrete Graphics Solutions
ATI Radeon HD 7650A (MXM)
NOTE: When this MXM graphics card is installed in the USDT all three monitor ports are active. The
integrated processor graphics will operate the top DisplayPort while the discrete AMD graphics will
operate the bottom Multi-Stream DisplayPort and the VGA output.
X
AMD Radeon HD 6350 (512 MB) PCIe x16
(includes a DMS-59 to Dual VGA Y Cable)
X
QuickSpecs
HP Compaq Elite 8300 Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14268 North America — Version 41 — November 22, 2013 Page 7

HP Compaq Elite 8300 Specifications

General

Operating temperature (T-T)	10 - 35 °C
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
HDD size	3.5 \
Dimensions (WxDxH)	178 x 445 x 448 mm
Microphone in	Yes
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
PCI slots	3
Chassis type	Mini-Tower
Product type	PC barebone
Product color	Gray
Audio system	HD
Motherboard chipset	Intel® Q77 Express
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Power supply	320 W
Operating system installed	No
Processor model	-
Processor family	Intel

Weight and Dimensions

Weight	11200 g
