HP Compaq Elite 8300 Specification

Introduction
The NVIDIA GeForce GT630 DP (2GB) PCIe x16 Card Graphics Card provides a full height, PCI Express x16 graphics add-in card solution
based on the NVIDIA Kepler Architecture GPU. The card is designed to support three display connections through its DVII, and two
DisplayPort connectors.
An ideal solution for desktop PC customers seeking enhanced 2D and advanced 3D graphics performance, the NVIDIA GeForce GT630
DP (2GB) PCIe x16 Cards are an excellent choice for business users who want run multiple displays from a single graphics board.
Engage in Web conferencing or video or photo editing, while improving your everyday business PC experience with better graphics and
excellent visual display quality.
The NVIDIA GeForce GT630 DP (2GB) PCIe x16 Cards deliver superior PCI Express (PCIe) Gen 3 features including:
Unprecedented flexibility for new applications and enhanced performance
Support for NVIDIA surround technology
Run multiple displays from a single graphics card
Full 16 lane PCIe Generation 3 bus support with peak bandwidth support
Wireless Display ready for future support
NOTE: Graphics cards use part of the total system memory (RAM) for graphics performance. System memory dedicated to graphics
performance is not available for other use by other programs.
Key Benefits
2 GB of DDR3 dedicated on-board graphics frame buffer memory removing the need to share PC system memory
Features the latest NVIDIA Kepler Architecture GPU Support
Run multiple displays from a single graphics board
DisplayPort 1.2 hardware ready for future multi-monitor support
Provides Dual-Link (DL) DVI-I and two multimode DisplayPort output ports (useable at the same time)
Also supports legacy displays using adapters:
DVII to VGA adapter (1 included)
HP DP to DVI-D adapter FH973AA (1 included)
HP DP to HDMI adapter BP937AA (optional)
HP DP to VGA adapter AS615AA (optioal)
HP DP to dual link DVI-D adapter NR078AA (optional)
Supports Audio over DisplayPort for users who need audio with video thru the DisplayPort connector. Audio is also supported
with the optional HP DP to HDMI adapter (BP937AA).
Audio is also supported using DVI to HDMI adapters (Adapters not available from HP)
Conforms to full PCI Express 3.0A specification for full height form factor (x16 lanes native PCI Express implementation)
HDCP supported on DVI and DisplayPort outputs
DirectX11 support in hardware for optimal performance in DX11 applications
OpenGL 4.2 support in hardware for optimal performance with OpenGL applications
NVIDIA GeForce GT630 DP (2GB)) PCIe x16 Card
Memory Peak theoretical memory bandwidth
2 GB DDR3 128 bit 28.5 GB/s
Compatibility
QuickSpecs
HP Compaq Elite 8300 Business PC
Technical Specifications - Graphics
DA - 14268 North America — Version 41 — November 22, 2013 Page 30

HP Compaq Elite 8300 Specifications

General

Operating temperature (T-T)	10 - 35 °C
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
HDD size	3.5 \
Dimensions (WxDxH)	178 x 445 x 448 mm
Microphone in	Yes
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
PCI slots	3
Chassis type	Mini-Tower
Product type	PC barebone
Product color	Gray
Audio system	HD
Motherboard chipset	Intel® Q77 Express
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Power supply	320 W
Operating system installed	No
Processor model	-
Processor family	Intel

Weight and Dimensions

Weight	11200 g
