5–26 Maintenance and Service Guide
Removal and Replacement Procedures
5.11 LED Board
✎
This section applies only to full-featured models.
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.9).
3. Remove the switch cover (Section 5.10).
4. Turn the notebook upside down with the rear panel
toward
you.
5. Turn the switch cover upside down.
LED Board Spare Part Number Information
LED board (includes LED board cable) 378228-001
