Removal and Replacement Procedures
Maintenance and Service Guide 5–37
5.18 Display Assembly
1. Prepare the notebook for disassembly (Section 5.3),
and then remove the following components:
a. Memory module/Mini PCI compartment cover
(Section 5.6)
b. Optical drive (Section 5.8)
c. Keyboard (Section 5.9)
d. Switch cover (Section 5.10)
2. Disconnect the wireless antenna cables from the Mini PCI
communications board (
Section 5.7).
3. Turn the notebook display-side up with the front toward you.
4. Open the notebook as far as possible.
Display Assembly Spare Part Number Information
15.0-inch, SXGA+WVA, TFT
15.0-inch, XGA, TFT
14.1-inch, XGA, TFT
378210-001
378209-001
378208-001
To Next Page
