5–48 Maintenance and Service Guide
Removal and Replacement Procedures
5.21 Digital Media Board
✎
This section applies only to full-featured models.
1. Prepare the notebook for disassembly (Section 5.3),
and then remove the following components:
a. Memory module/Mini PCI compartment cover
(Section 5.6)
b. Optical drive (Section 5.8)
c. Keyboard (Section 5.9)
d. Switch cover (Section 5.10)
e. Display assembly (Section 5.18)
f. Top cover (Section 5.19)
g. Speaker (Section 5.20)
Digital Media Board Spare Part Number Information
Digital media board (includes digital media board cable) 378229-001
