A–4
Maintenance and Serv
ice Gui
de
Connec
tor P
in
As
signments
Ta
b
l
e
A
-
5
External Monitor
Pin
Signal
Pin
Signal
1
Red analog
9
+5 VDC
2
Green analog
10
Ground
3
Blue analog
11
Monitor detect
4
Not connected
12
DDC 2B data
5
Ground
13
Horizontal sync
6
Ground analog
14
V
er
tical sync
7
Ground analog
15
DDC 2B cloc
k
8
Ground analog
179
181
