Hard drive
Description Spare part number
2.0-TB, 5400-rpm 801888-005
1.5-TB, 5400-rpm 747375-005
1.0-TB, 5400-rpm 778192-005
1.0-TB, 5400-rpm, hybrid 731999-005
750-GB, 5400-rpm 778190-005
750-GB, 5400-rpm, hybrid 732001-005
500-GB, 5400-rpm for use with HP ENVY 15 Notebook PC computer models 778188-005
Hard Drive Hardware Kit (not illustrated):
For use only on HP ENVY 17 Notebook PC computer models 763705-001
For use only on HP ENVY 17 Notebook PC computer models 762504-001
Before removing the primary hard drive or secondary hard drive (select models only), follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 32).
5. Remove the optical drive (see Optical drive on page 33).
6. Remove the base enclosure and keyboard/top cover (see Keyboard/top cover on page 36).
7. Remove the USB connector board (see USB board on page 56).
Remove the primary hard drive:
▲
Disconnect the hard drive cable from the system board (1), and then tilt the hard drive (2) and lift to
remove it (3).
Component replacement procedures 57
