TV tuner antenna
Description Spare part number
TV tuners
●
ATSC/NTSC TV tuner antenna
482900-001
●
TV tuner antenna with PAL jack
482900-002
●
ATSC/NTSC TV tuner
482899-001
●
DVB-T/ANG Integrated TV tuner
482899-002
●
DVB-T tuner 482899-003
If it has been determined that the TV tuner antenna cable is the component that must be replaced to
complete the computer repair, follow the procedures in this section to replace the cable.
Before removing the TV antenna cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 55)
5. Remove the keyboard (see
Keyboard on page 72)
6. Remove the keyboard cover (see
Keyboard cover on page 76)
7. Remove the display assembly (see
Display assembly on page 83)
8. Remove the top cover (see
Top cover on page 95)
9. Remove the USB board (see
USB board on page 106)
Remove the TV tuner antenna cable:
1. Disconnect the TV tuner antenna cable from the system board (1).
108 Chapter 4 Removal and replacement procedures
