HP E27 G5 User Manual

19
Connector repair
This procedure includes HDMI, DisplayPort and USB connectors.
The connectors are on the main board (board part number CBPR2RTHPQ1).
The connector identifiers are as follows:
Connector
Location
DP
CN502
HDMI
CN501
USB UP
CN105
USB 1
、
2
、
CN104\ CN106
The connectors are on the USB board (board part number USB2QC2).
Connector
Location
USB3/4
CN1004/CN1005
Main Board
CN502
CN501
CN105
CN
104
CN106
CN
1005
CN1004

HP E27 G5 Specifications

General

Color gamut	99 %
Pixel pitch	0.31 x 0.31 mm
Screen shape	Flat
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display brightness (peak)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	50 W
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	160 mm
Package width	699 mm
Package height	446 mm
Package weight	10880 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 20 °
Height adjustment	150 mm
Panel mounting interface	100 x 100 mm
Product color	Black
Country of origin	China
Market positioning	Business
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	227 mm
Width (with stand)	612 mm
Height (with stand)	546 mm
Weight (with stand)	6960 g
Depth (without stand)	4.5 mm
Width (without stand)	611.7 mm
Height (without stand)	363.3 mm
Weight (without stand)	4830 g
