Low-voltage hard drive or solid-state drive
NOTE: The 4.57-cm (1.80-in) hard drive and solid-state drive spare part kit includes a hard drive or
solid-state drive bracket.
Description Spare part number
4.57-cm (1.80-in), 320-GB, 5400-rpm hard drive 614537-001
4.57-cm (1.80-in), 250-GB, 5400-rpm hard drive 598778-001
4.57-cm (1.80-in), 160-GB, 5400-rpm hard drive 598777-001
4.57-cm (1.80-in), 160-GB, solid-state drive 598782-001
4.57-cm (1.80-in), 80-GB, solid-state drive 602675-001
Before removing the low-voltage hard drive or solid-state drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 48).
5. Remove the memory module compartment cover (see
Expansion memory module on page 52).
Remove the low-voltage hard drive or solid-state drive:
1. Position the computer with the front toward you.
2. Loosen the 2 captive screws (1) that secure the hard drive shield to the computer.
54 Chapter 4 Removal and replacement procedures ENWW
