h. Select the Main menu, then Save Changes and Exit.
i. Reboot the system. If the system has a Trusted Platform Module (TPM) and/or fingerprint sensor,
one or two prompts will appear. One to clear the TPM and the other to Reset Fingerprint Sensor;
press F1 to accept or F2 to reject.
j. Remove all power and system batteries for at least 24 hours.
2. Remove and retain the storage drive or clear the contents of the drive.
Clear the drive contents by using the BIOS Setup Secure Erase command option, or by using a third party
utility designed to erase data from an SSD. To run Secure Erase, follow these steps:
a. Enter BIOS Setup by powering on the system, and then pressing F10 when prompted near
the bottom of the display.
b. Select the Security menu and scroll down to the Utilities menu.
c. Select Hard Drive Tools.
d. Under Utilities, select Secure Erase, and then select the desired hard drive.
Non-volatile memory usage
Non Volatile
Memory Type
Amount
(Size)
Does this
memory
store
customer
data?
Does this
memory
retain data
when power
is removed?
What is
the purpose of
this memory?
How is data input into this
memory?
How is this memory write
protected?
HP Sure Start
flash (select
models only)
2 MB No Yes Provides
protected
backup of
critical System
BIOS code, EC
firmware, and
critical PC
configuration
data for select
platforms that
support HP Sure
Start.
For more
information,
see Using HP
Sure Start
(select models
only)
on page 124.
Data cannot be written to this
device via the host processor.
The content is managed
solely by the HP Sure Start
Embedded Controller.
This memory is protected
by the HP Sure Start
Embedded Controller.
Real Time Clock
(RTC) battery
backed-up CMOS
configuration
memory (CMOS)
256 Bytes No Yes Stores system
date and time
and limited
keyboard
controller data.
Using the F10 Setup utility or
changing the Microsoft
Windows date & time.
This memory is not write-
protected. HP
recommends password
protecting the F10 Setup
utility.
120 Chapter 10 Statement of Volatility ENWW

HP EliteBook 850 G2 Specifications

General

Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-5500U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-5500 Mobile Series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.4 GHz
Processor cache type	L3
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Maximum number of PCI Express lanes	12
On-board graphics card ID	0x1616
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 5500
Graphics card Open GL support	Yes
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	16 GB
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	11.2
On-board graphics card dynamic frequency (max)	950 MHz
Processor code	SR23W
Processor ARK ID	85214
Processor package size	40 x 24 x 1.3 mm
CPU configuration (max)	1
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology	-
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Power adapter depth	40 mm
Power adapter width	95 mm
Power adapter height	26.5 mm
Intel segment tagging	Enterprise
Intel® Virtualization Technology (Intel® VT)	VT-x, VT-d
Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 8 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Total storage capacity	500 GB
Compatible memory cards	SD, SDHC, SDXC
Display surface	Matt
Display diagonal	15.6 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
Display number of colors	16.78 million colors
Audio system	DTS Studio Sound
Video capturing speed	30 fps
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Battery voltage	11.1 V
Battery capacity	4504 mAh
Battery life (max)	- h
Number of battery cells	3
AC adapter power	45 W
AC adapter frequency	47/63 Hz
AC adapter input voltage	90 - 265 V
AC adapter output voltage	19.5 V
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	253.6 mm
Width	375.5 mm
Height	21.4 mm
Weight	1830 g
