HP EliteBook 850 G2 User Manual

1. Access HP Computer Setup (F10).
a. Turn on or restart the device, and then press esc while the “Press the ESC key for Startup Menu”
message is displayed at the bottom of the screen.
b. Press f10 to enter Computer Setup.
NOTE: If the BIOS is protected with an Administrator password, enter the password.
2. Select Advanced, and then select HP Touchpoint Manager Options.
3. Clear the Allow Activation check box.
4. Select Save changes and exit.
Display panel
NOTE: Non-TouchScreen display assemblies are spared at the subcomponent level only. TouchScreen
display assemblies are spared only as whole unit replacement kits.
On non-TouchScreen computer models, the display bezel, display panel, and webcam/microphone module
can be removed with the display assembly still installed on the computer. The following section provides
instructions on how to remove the these components without removing the display assembly from
the computer.
See Display assembly on page 99 later in this chapter for information on removing the display assembly
and other display assembly subcomponents.
Before removing the display bezel, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the service cover (see Service cover on page 51).
5. Remove the battery (see Battery on page 53).
Remove the display bezel:
1. Flex the inside edges of the bottom edge (1), the left and right sides (2), and the bottom edge (3) of
the display bezel until the bezel disengages from the display enclosure.
2. Remove the bezel (4).
The display bezel is available using the following spare part numbers:
●
730952-001 – For use only on HP EliteBook 840 G2 Notebook PC computer models
●
784451-001 – For use only on HP EliteBook 740 G2 Notebook PC computer models
●
730953-001 – For use only on HP ZBook 14 G2 Mobile Workstation computer models
70 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts ENWW

HP EliteBook 850 G2 Specifications

General

Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-5500U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-5500 Mobile Series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.4 GHz
Processor cache type	L3
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Maximum number of PCI Express lanes	12
On-board graphics card ID	0x1616
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 5500
Graphics card Open GL support	Yes
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	16 GB
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	11.2
On-board graphics card dynamic frequency (max)	950 MHz
Processor code	SR23W
Processor ARK ID	85214
Processor package size	40 x 24 x 1.3 mm
CPU configuration (max)	1
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology	-
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Power adapter depth	40 mm
Power adapter width	95 mm
Power adapter height	26.5 mm
Intel segment tagging	Enterprise
Intel® Virtualization Technology (Intel® VT)	VT-x, VT-d
Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 8 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Total storage capacity	500 GB
Compatible memory cards	SD, SDHC, SDXC
Display surface	Matt
Display diagonal	15.6 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
Display number of colors	16.78 million colors
Audio system	DTS Studio Sound
Video capturing speed	30 fps
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Battery voltage	11.1 V
Battery capacity	4504 mAh
Battery life (max)	- h
Number of battery cells	3
AC adapter power	45 W
AC adapter frequency	47/63 Hz
AC adapter input voltage	90 - 265 V
AC adapter output voltage	19.5 V
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	253.6 mm
Width	375.5 mm
Height	21.4 mm
Weight	1830 g
