HP EliteBook 850 G2 User Manual

5 Removal and replacement procedures for
Customer Self-Repair parts
CAUTION: The Customer Self-Repair program is not available in all locations. Installing a part not
supported by the Customer Self-Repair program may void your warranty. Check your warranty to determine
if Customer Self-Repair is supported in your location.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Component replacement procedures
NOTE: Please read and follow the procedures described here to access and replace Customer Self-Repair
parts successfully.
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service label at the bottom of your computer. See Locating the product name, serial number,
product number, warranty information, and model number on page 27 for details.
This chapter provides removal and replacement procedures for Customer Self-Repair parts.
There are as many as 13 screws that must be removed, replaced, and/or loosened when servicing
the Customer Self-Repair parts. Make special note of each screw size and location during removal
and replacement.
Service cover
Description Spare part number
For use only on HP EliteBook 840 G2 Notebook PC computer models 766324-001
For use only on HP EliteBook 740 G2 Notebook PC computer models 784452-001
For use only on configure to order (CTO) computer models 745311-001
For use only on HP ZBook 14 G2 Mobile Workstation computer models 730961-001
Before removing the service cover, follow these steps:
ENWW Component replacement procedures 51

HP EliteBook 850 G2 Specifications

General

Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-5500U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-5500 Mobile Series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.4 GHz
Processor cache type	L3
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Maximum number of PCI Express lanes	12
On-board graphics card ID	0x1616
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 5500
Graphics card Open GL support	Yes
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	16 GB
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	11.2
On-board graphics card dynamic frequency (max)	950 MHz
Processor code	SR23W
Processor ARK ID	85214
Processor package size	40 x 24 x 1.3 mm
CPU configuration (max)	1
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology	-
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Power adapter depth	40 mm
Power adapter width	95 mm
Power adapter height	26.5 mm
Intel segment tagging	Enterprise
Intel® Virtualization Technology (Intel® VT)	VT-x, VT-d
Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 8 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Total storage capacity	500 GB
Compatible memory cards	SD, SDHC, SDXC
Display surface	Matt
Display diagonal	15.6 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
Display number of colors	16.78 million colors
Audio system	DTS Studio Sound
Video capturing speed	30 fps
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Battery voltage	11.1 V
Battery capacity	4504 mAh
Battery life (max)	- h
Number of battery cells	3
AC adapter power	45 W
AC adapter frequency	47/63 Hz
AC adapter input voltage	90 - 265 V
AC adapter output voltage	19.5 V
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	253.6 mm
Width	375.5 mm
Height	21.4 mm
Weight	1830 g
