HP EliteBook x360 830 G8 User Manual

11 Statement of memory volatility
For general information regarding nonvolatile memory in HP business computers, and to restore nonvolatile
memory that can contain personal data after the system has been turned o and the hard drive has been
removed, use these instructions.
HP business computer products that use Intel®-based or AMD®-based system boards contain volatile DDR
memory. The amount of nonvolatile memory present in the system depends upon the system
conguration.
Intel-based and AMD-based system boards contain nonvolatile memory subcomponents as originally shipped
from HP, with the following assumptions:
● No subsequent modications were made to the system.
● No applications, features, or functionality were added to or installed on the system.
Following system shutdown and removal of all power sources from an HP business computer system,
personal data can remain on volatile system memory (DIMMs) for a nite period of time and also remains in
nonvolatile memory. Use the following steps to remove personal data from the computer, including the
nonvolatile memory found in Intel-based and AMD-based system boards.
NOTE: If your tablet has a keyboard base, connect to the keyboard base before beginning steps in this
chapter.
Current BIOS steps
Use these instructions to restore nonvolatile memory.
1. Follow these steps to restore the nonvolatile memory that can contain personal data. Restoring or
reprogramming nonvolatile memory that does not store personal data is neither necessary nor
recommended.
a. Turn on or restart the computer, and then quickly press esc.
NOTE: If the system has a BIOS administrator password, enter the password at the prompt.
b. Select Main, select Apply Factory Defaults and Exit, and then select Yes to load defaults. The
computer restarts.
c. During the restart, press esc while the "Press the ESC key for Startup Menu" message is displayed
at the bottom of the screen.
NOTE: If the system has a BIOS administrator password, enter the password at the prompt.
d. Select the Security menu, select Restore Security Settings to Factory Defaults, and then select
Yes to restore security level defaults. The computer reboots.
e. During the reboot, press esc while the "Press the ESC key for Startup Menu" message is displayed
at the bottom of the screen.
NOTE: If the system has a BIOS administrator password, enter the password at the prompt.
f. If an asset or ownership tag is set, select the Security menu and scroll down to the Utilities menu.
Select System IDs, and then select Asset Tracking Number. Clear the tag, and then make the
selection to return to the prior menu.
73

HP EliteBook x360 830 G8 Specifications

General

Color gamut	72 %
RGB color space	NTSC
Display diagonal	13.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	400 cd/m²
Native aspect ratio	16:9
Display diagonal (metric)	33.8 cm
Processor cache	8 MB
Processor cores	4
Processor model	i5-1135G7
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	2.4 GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor manufacturer	Intel
Processor boost frequency	4.2 GHz
Configurable TDP-down frequency	0.9 GHz
ECC	No
Memory slots	1x SO-DIMM
Internal memory	16 GB
Memory clock speed	3200 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 16 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	512 GB
Number of SSDs installed	1
Battery weight	213 g
Battery capacity	53 Wh
Number of battery cells	3
Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Market positioning	Premium
Pointing device	Clickpad
Input device model	Clavier HP Premium
Keyboard special features	Étanche
Operating system architecture	64-bit
HP segment	Business
HP front camera	HP Webcam HD IR
HP speaker type	HP Dual Speakers
HP Security tools	Absolute persistence module; HP DriveLock and Automatic DriveLock; HP Secure Erase; Power-on authentication; Preboot authentication; TPM 2.0 embedded security chip shipped with Windows 10 (Common Criteria EAL4+ Certied); HP Sure Click; Windows Defender; HP Sure Sense; BIOS Update via Network; Support for chassis padlocks and cable lock devices; HP Sure Start Gen6; HP BIOSphere Gen6; HP Client Security Manager Gen7
HP Management tools	HP Driver Packs; HP System Software Manager (SSM); HP BIOS Cong Utility (BCU); HP Client Catalog; HP Manageability Integration Kit Gen4; HP Client Management Script Library (download)
HP Software provided	HP Connection Optimizer; HP Image Assistant; HP Hotkey Support; HP Noise Cancellation Software; HP Support Assistant; Buy Office (Sold separately); HP Power Manager; HP WorkWell; myHP; HP Privacy Settings; HSA Fusion for Commercial; HSA Telemetry for Commercial; Touchpoint Customizer for Commercial; HP Notications; HP QuickDrop; Tile App; HP Wireless Button Drive
AC adapter power	65 W
Discrete graphics card model	Not available
On-board graphics card model	Intel Iris Xe Graphics
Number of built-in speakers	2
Front camera HD type	HD
Front camera signal format	720p
MIMO type	Multi User MIMO
Antenna type	2x2
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Charging port type	USB Type-C
USB 2.0 ports quantity	-

Weight and Dimensions

Depth	205 mm
Width	307.5 mm
Height	17.9 mm
Weight	1350 g
