Page #110 background imageLoading...
Page #110 background image
8 Backing up, restoring, and recovering
Backing up, restoring, and recovering in Windows 10
This chapter provides information about the following processes. The information in the chapter is standard
procedure for most products.
Creating recovery media and backups
Restoring and recovering your system
For additional information, refer to the HP support assistant app.
Type support in the taskbar search box, and then select the HP Support Assistant app.
or –
Click the question mark icon in the taskbar.
IMPORTANT: If you will be performing recovery procedures on a tablet, the tablet battery must be at least
70% charged before you start the recovery process.
IMPORTANT: For a tablet with a detachable keyboard, connect the keyboard to the keyboard dock before
beginning any recovery process.
Creating recovery media and backups
The following methods of creating recovery media and backups are available on select products only. Choose
the available method according to your computer model.
Use HP Recovery Manager to create HP Recovery media after you successfully set up the computer. This
step creates a backup of the HP Recovery partition on the computer. The backup can be used to reinstall
the original operating system in cases where the hard drive is corrupted or has been replaced. For
information on creating recovery media, see Creating HP Recovery media (select products only)
on page 102. For information on the recovery options that are available using the recovery media, see
Using Windows tools on page 103.
Use Windows tools to create system restore points and create backups of personal information.
For more information, see Recovering using HP Recovery Manager on page 104.
NOTE: If storage is 32 GB or less, Microsoft System Restore is disabled by default.
Creating HP Recovery media (select products only)
If possible, check for the presence of the Recovery partition and the Windows partition. From the Start menu,
select File Explorer, and then select This PC.
If your computer does not list the Windows partition and the Recovery partition, you can obtain recovery
media for your system from support. See the Worldwide Telephone Numbers booklet included with the
computer. You can also nd contact information on the HP website. Go to http://www.hp.com/support,
select your country or region, and follow the on-screen instructions.
102 Chapter 8 Backing up, restoring, and recovering

Table of Contents

Other manuals for HP EliteOne 800 G3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteOne 800 G3 and is the answer not in the manual?

HP EliteOne 800 G3 Specifications

General IconGeneral
Tcase71 °C
Bus typeDMI3
SteppingR0
Processor codeSR2BX
Processor cache6 MB
Processor cores4
Processor modeli5-6500
System bus rate8 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-6500 Desktop series
Processor socketLGA 1151 (Socket H4)
Processor codenameSkylake
Processor frequency3.2 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Conflict-Free processorYes
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.6 GHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)65 W
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor1.35 V
Memory clock speeds supported by processor2133, 1333, 1600, 1866 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor64 GB
Discrete graphics cardNo
On-board graphics card ID1912
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 530
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1050 MHz
Number of displays supported (on-board graphics)3
Color gamut72 %
RGB color spaceNTSC
Display diagonal23.8 \
Native aspect ratio16:9
Product typeAll-in-One PC
Motherboard chipsetIntel® Q270
Memory slots2
Internal memory8 GB
Memory slots typeSO-DIMM
Memory clock speed2400 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory32 GB
Memory layout (slots x size)1 x 8 GB
SSD capacity256 GB
SSD interfacePCI Express
Storage mediaSSD
Optical drive typeDVD-RW
Card reader integrated-
Number of storage drives installed1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
Product colorBlack, Silver
Country of originChina
Antenna type2x2
Wi-Fi standardsWi-Fi 5 (802.11ac)
Ethernet LAN data rates10, 100, 1000 Mbit/s
AC adapter power180 W
Recovery operating systemWindows 10 Pro
Operating system installedWindows 7 Professional
Scalability1S
Processor ARK ID88184
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.2, AVX 2.0, SSE4.1
Thermal solution specificationPCG 2015C
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)53.8 mm
Width (with stand)539.6 mm
Height (with stand)314.8 mm
Weight (with stand)6030 g
