Credit card reader board
NOTE: The credit card reader board spare part kits do not include the respective cables. The cables are
included in the Cable Kit, spare part number 744031-001.
Description Spare part number
Left-side credit card reader board 744027-001
Right-side credit card reader board 744028-001
Before removing the credit card reader boards, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet or the Retail Jacket.
3. Disconnect all external devices from the Retail Jacket.
4. Remove the top cap (see Top cap on page 63).
5. If installed, remove the tablet from the Retail Jacket (see Top cap on page 63).
6. Remove the front cover (see Front cover on page 65).
Remove the credit card reader boards:
1. Remove the Phillips PM1.9×3.0 screw (1) that secures the left-side credit card reader board to the rear
cover.
2. Turn the left-side credit card reader board (2) over so the ZIF connector on the back of the board is
accessible.
74 Chapter 5 Removal and replacement procedures
