HP ENVY 14 Maintenance And Service Guide

1 Product description
Category Description
Product Name HP ENVY 14 Notebook PC
Processors Processors are attached to the system board.
Intel 5th generation processors:
®
Intel Core™ i7-5500U 2.4 GHz processor, SC turbo up to 3.0 GHz, 1600 MHz (4 MB L3 cache, dual core, 15 W)
Intel Core i5-5200U 2.2 GHz processor, SC turbo up to 2.7 GHz, 1600 MHz (3 MB L3 cache, dual core, 15 W)
Intel 4th generation processors:
Intel Core i7-4510U 2.0 GHz processor, SC turbo up to 3.1 GHz, 1600 MHz (4 MB L3 cache, dual core, 15 W)
Intel Core i5-4210U 1.7 GHz processor, SC turbo up to 2.7 GHz, 1600 MHz (3 MB L3 cache, dual core, 15 W)
Chipset Intel Lynx Point-LP PCH, for use with 4th Generation Intel Core processors
Graphics Internal graphics:
Intel HD Graphics 4400, for use with 4th Generation Intel Core processors
Switchable discrete graphics:
HD decode, DX11, and HDMI
Optimus
GPS (GPU Performance Scaling)
NVIDIA GeForce GTX 850M with up to 4096 MB of dedicated video memory (256 M x16 DDR3 900 MHz x 8
PCs, 1 GHz downgrade to 900 MHz), 128 bit
NVIDIA GeForce 840M with up to 2048 MB of dedicated video memory (256 M x16 DDR3 900 MHz x 4 PCs, 1
GHz downgrade to 900 MHz), 64 bit
Panel 35.56 cm (14 in), high-definition (HD), white light-emitting diode (WLED), BrightView (1366×768) flat
display, 3.6 mm, SVA, typical brightness: 200 cd/m
2
(nits)
35.56 cm (14 in), HD, WLED, Antiglare (1366×768) flat display, 3.6 mm, SVA, typical brightness: 200 cd/m
2
(nits)
35.56 cm (14 in), FHD, WLED, Antiglare (1920x1080) slim display, 3.0 mm, typical brightness: 300 cd/m
2
(nits) – touch and non-touch
16:9 Ultra Wide Aspect Ratio
Memory Supports the following configurations:
●
16384 MB (8192 MB×2)
●
12288 MB (8192 MB×1+ 4096 MB×1)
●
8192 MB (8192 MB×1 or 4096 MB×2)
●
4096 MB (4096 MB×1)
Two SODIMM memory module slots
DDR3L-1600 MHz dual channel support
1

HP ENVY 14 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Display diagonal	14.5 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 2 GB
Discrete graphics card model	AMD Radeon HD 5650
Maximum graphics card memory	2.714 GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Power supply type	AC
Wireless technology	Wi-Fi
Graphics card family	AMD
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Home Premium
Sustainability certificates	ENERGY STAR
AC adapter power	90 W
Number of battery cells	8
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Cable lock slot type	Kensington
Product color	Black
Country of origin	China
Pointing device	Touchpad
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	237 mm
Width	356 mm
Weight	2380 g
Height (rear)	28.2 mm
Height (front)	27.7 mm
