Hard drive
Description Spare part number
1.5 TB 5400-RPM SATA RAW 9.5 mm 747375-005
1-TB, 5400-RPM 778192-005
1-TB, 5400-RPM hybrid 731999-005
750-GB, 5400-RPM 778190-005
750-GB, 5400-RPM hybrid 732001-005
500 GB, 5400-RPM for use with HP ENVY 15 Notebook PC computer models 778188-005
Hard Drive Hardware Kit for use with HP ENVY 15 Notebook PC computer models 762504-001
Hard Drive Hardware Kit for use with HP ENVY 17 Notebook PC computer models 763705-001
Before removing the primary hard drive or secondary hard drive (select models only), follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 37).
5. Remove the optical drive (see
Optical drive on page 38).
6. Remove the base enclosure and top cover (see
Base enclosure on page 41).
7. Remove the USB connector board (see
USB board on page 61).
Remove the primary hard drive:
▲
Disconnect the hard drive cable from the system board (1), and then tilt the hard drive (2) and lift to
remove it (3).
62 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
