Hard drive specications
1-TB, 5400-rpm* 500-GB, 5400-rpm* 750-GB, 5400-rpm*
Dimensions
Height 7.0 mm 7.0 mm 7.0 mm
Length 100.4 mm 100.4 mm 100.4 mm
Width 69.9 mm 69.9 mm 69.9 mm
Weight 110 g 110 g 110 g
Interface type SATA SATA SATA
Transfer rate (synchronous,
maximum)
1.2 GB/sec 1.1 GB/sec 1.1 GB/sec
Security ATA security ATA security ATA security
Seek times (typical read, including setting)
Single track 3 ms 1.5 ms 2 ms
Average (read/write) 13 ms 11/13 ms 14 ms
Maximum 24 ms 22 ms 26 ms
Logical blocks 1,953,525,168 976,773,168 1,465,822,484
Disk rotational speed 5400 rpm 5400 rpm 5400 rpm
Operating temperature 0°C to 60°C (32°F to 140°F) 0°C to 60°C (32°F to 140°F) 0°C to 60°C (32°F to 140°F)
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less.
NOTE: Certain restrictions and exclusions apply. Contact technical support for details.
78 Chapter 11 Specications
