HP4402.book : chapter1.fm 15 Tue Apr 22 15:20:23 1997
Getting Star
ted
Adjusting the Carrying Handle
HP
EPM-441A User’s Guide
1-15
Adjusting the Carrying Handle
T
o adjust the position, grasp the handle by the sides and pull outward.
Rotate the handle to the desired position.
Bench top viewing positions
Carrying position
36
38
