Attaching the stand base
1. Remove the stand/base assembly, and then lift the monitor from the box and place it face down on a
flat surface.
2. Position the stand over the base, and press down firmly to lock it in place.
3. Insert the two tabs on the stand into the bracket on the back of the display head until they click into
place.
CAUTION: Do not touch the surface of the LCD panel. Pressure on the panel may cause non-uniformity of
color or disorientation of the liquid crystals. If this occurs the screen will not recover to its normal condition.
6 Chapter 3 Setting up the monitor
