13 Product specifications
System specifications
NOTE: Not all models described are available in all regions. For more information on specifications
for your particular model, on the Travel Companion, tap Start > Settings > System tab > System
Details.
System Feature Description
Processor Centrality Titan
Operating System Microsoft® Windows Mobile® CE
Memory Up to 2.0 GB flash ROM for persistent storage, depending on
model
128 MB SDRAM for running applications
External Power AC Input: 100~240 Vac, 50/60 Hz, AC Input current: 0.2 A ac
max Output Voltage: 5Vdc (typical)
Display 4.3" WVGA 800x480 TFT with touch screen, antiglare,
landscape oriented, 16bit RGB depth
LED Backlight PLACEHOLDER
SD Slot Supports SD memory
Antenna Internal Bluetooth antenna
Audio Integrated microphone, speaker, and one 3.5–mm stereo
headset jack, 5–band equalizer and 3D sound adjustment
Battery 1,700 mAh Li-ion removable/rechargeable battery
Bluetooth Bluetooth 2.0 with Enhanced Data Rate, typical 10 meter range
(approximately 33 feet)–High-speed, low-power, short-range
wireless communication with other Bluetooth devices
LED Indicators:
Charge and Notification LED
●
Flashing amber indicates an event notification or alarm
on the Travel Companion.
●
Solid amber indicates unit is charging.
●
Solid green indicates unit is fully charged.
Wireless LED
●
Flashing blue indicates:
◦
Bluetooth is on
●
LED off indicates Bluetooth is off
GPS Receiver PLACEHOLDER
GPS Antenna PLACEHOLDER
22 Chapter 13 Product specifications
