Cable and Connector Pin-Outs
V.35 WAN Cable—Minimum Pin-Outs
WAN link
end
34-pin male
Router
end
62-pin male
CCITT Signal Name
and Circuit
B 9 102 Signal Ground
22
23
24
25
26
27
47
31
32
52
50
C 57 105 Ready to Send
D 4 106 Clear to Send
E 46 107 Data Mode
F 6 109 Receiver Ready
H 58 108.2 Terminal Ready
J 48 Reserved
P 21 103 Send Data, A
R 20 104 Receive Data, A
S 42 103 Send Data, B
T 41 104 Receive Data, B
U 61 Transmit Timing, A
V 18 115 Receive Timing, A
W 60 Transmit Timing, B
X 39 115 Receive Timing, B
Y 19 114 Send Timing, A
AA 40 114 Send Timing, B
Cables and Connectors
Cable and Connector Pin-Outs
A-4
To Next Page
