4-10
Planning and Implementation for the Series 5400zl Switch
Planning Your PoE Configuration
Planning and
Implementation for the
Series 5400zl Switch
ProCurve 5406zl Configurations using the Power Supply Shelf
Figure 4-6. Connecting the EPS to one 5406zl switch
Figure 4-7. Connecting the EPS to two 5406zl switches
As shown in figures 4-6 and 4-7 the Power Supply Shelf can be connected to
the 5406zl to supply extra or redundant PoE power to the PoE modules
installed in the 5406zl.
To Power
Source
EPS Cables
To Power
Source
5406zl
EPS Cables
5406zl
5406zl
To Power
Source
To P o w er
Source
