Network Interface Module LEDs
Network Interface Module LEDs
Network Connectivity Modules Port LEDs
There are two LEDs for each port:
■ The Link LED lights green with a valid connection and orange if there is
a fault or alert condition.
■ The Mode LED lights according to the LED mode selected on the chassis.
The LED mode is selected on the Management Module for the E5400 zl
swit
ches, and on the System Support Module (SSM) on the Switch E8212 zl.
The LED mode that is selected is indicated by the following five LEDs that are
located near the LED mode selection button.
Network Ports Mode
LED Display
Description
Act Activity Transmit or receive traffic present
FDx Full Duplex Full duplex mode of operation
Spd Indicates the Port
LE
Ds are displaying
the connection
speed at which each
port is operating.
• If the Port LED is on continuously, the
p
ort is operating at 1000 Mbps.
• If the Port LED is flashing, the port is
opera
ting at 100 Mbps.
• If the Port LED is off, the port is
operating at 10 Mbps.
PoE Power over Ethernet • If the Mode LED is on, the port is
pr
oviding PoE power.
• If the Mode LED is off, the port is not
pr
oviding PoE power.
• If the Link LED is on, the port is enabled
for
PoE.
• If the Link LED is off, the port is disabled
for
PoE.
• If the Link LED is flashing, the port has
an error or the port is denied power due
to insufficient power.
Usr For future development
