HP L1502 LCD

Spare Parts List

Go to cover page

Mechanical parts

0030 313815755551 BEZEL ASSY

0040 313815755561 BACK COVER ASSY

0050 313815755202 STAND-HPL1502

Model :AJ6S50/02

Packing

0450 313815635922

CARTON-L1502

0451 313815635932

CUSHION-R

0452 313815635942

CUSHION-L

0453

313815621481

P.E.BAG

0456 313810659671

PE BAG

0601

313811705821 HP CD-ROM INF.

1057

313812874931 MAINSCORD

4444

313810610383 CD ROM - SERVICE MANUAL

4444

313810610384 SERVICE MANUAL

Accessory

PCB ASSY

1051

313815859621

SCALER ASSY

1054

313815859021

CONTROL ASSY

1052

823827715231

LIPS(AI-67MC)

Miscellanea

1055

313815859711 FRAME+WIRE

8061

313819872761 CBLE 3317 7/230/7-387 AWG28

1056

313819871221 CBLE-104 20/85/20-032 AWG28

1050 823827714731 TFT-LCD MOD LM150X08-A4

1050 823827714721 TFT-LCD MOD CLAA150XP01

LCD PANEL

PCB ASSY

1051 313815859621 SCALER ASSY

ELCAPSM RV2 16V 10U PM20 R

2401

223878615649

CER2 0603 X7R 16V 1N PM10 R

2402

223878615649

CER2 0603 X7R 16V 1N PM10 R

2403

223878615649

CER2 0603 X7R 16V 1N PM10 R

2408

223878615649

CER2 0603 X7R 16V 1N PM10 R

2409

223878615649

CER2 0603 X7R 16V 1N PM10 R

2414

223858615636

CER2 0603 X7R 50V 10N PM10 R

2415

223858615636

CER2 0603 X7R 50V 10N PM10 R

2416

223858615636

CER2 0603 X7R 50V 10N PM10 R

2442

223878615649

CER2 0603 X7R 16V 1N PM10 R

2443

223878615649

CER2 0603 X7R 16V 1N PM10 R

2444

223878615649

CER2 0603 X7R 16V 1N PM10 R

2445

202001293721

ELCAPSM RV2 16V 10U PM20 R

2446

202001293721

ELCAPSM RV2 16V 10U PM20 R

2448

223878615649

CER2 0603 X7R 16V 1N PM10 R

2449

223878615649

CER2 0603 X7R 16V 1N PM10 R

2450

223878615649

CER2 0603 X7R 16V 1N PM10 R

2451

223878615649

CER2 0603 X7R 16V 1N PM10 R

2452

223878615649

CER2 0603 X7R 16V 1N PM10 R

2453

223878615649

CER2 0603 X7R 16V 1N

PM10 R

2454

223878615649

CER2 0603 X7R 16V 1N PM10 R

2455

223878615649

CER2 0603 X7R 16V 1N PM10 R

2457

223878615649

CER2 0603 X7R 16V 1N PM10 R

2458

223878615649

CER2 0603 X7R 16V 1N PM10 R

2459

223878615649

CER2 0603 X7R 16V 1N PM10 R

2460

222224119876

CER2 1206 Y5V 10V 10U P8020 R

2463

222224119876

CER2 1206 Y5V 10V 10U P8020 R

2464

223878615649

CER2 0603 X7R 16V 1N PM10 R

2465

223878615649

CER2 0603 X7R 16V 1N PM10 R

2466

223878615649

CER2 0603 X7R 16V 1N PM10 R

2468

222224119876

CER2 1206 Y5V 10V 10U P8020 R

2469

223878615649

CER2 0603 X7R 16V 1N PM10 R

2477

202001293721

2482

222224119876

CER2 1206 Y5V 10V 10U P8020 R

2483 222224119876

CER2 1206 Y5V 10V 10U P8020 R

2304 223878615649 CER2 0603 X7R 16V 1N PM10 R

2305

202001293721

ELCAPSM RV2 16V 10U PM20 R

2306 CER1 0603 NP0 50V 22PPM5R

2307 CER1 0603 NP0 50V 22PPM5R

2309 CER2 0603 X7R 16V 1N PM10 R

2310 CER2 0603 Y5V 10V 470N P8020 R

2313 CER2 0603 X7R 16V 1N PM10 R

2501 CER2 0603 X7R 16V 1N PM10 R

2502 CER2 0603 X7R 16V 1N PM10 R

2505 CER2 0603 X7R 16V 1N PM10 R

2506 CER2 0603 X7R 16V 1N PM10 R

2509 CER2 0603 X7R 50V 10N PM10 R

2522 CER2 0603 X7R 50V 1N PM10 R

2524 CER2 0603 X7R 50V 1N PM10 R

2530 CER2 0603 X7R 50V 1N PM10 R

2532 CER2 0603 X7R 50V 1N PM10 R

2533 CER2 0603 X7R 50V 1N PM10 R

2534 ELCAPSM RV2 25V 47U PM20 R

2536 ELCAPSM RV2 25V 47U PM20 R

2218 CER1 0603 NP0 50V 33PPM5R

2219 CER1 0603 NP0 50V 220PPM5R

2221 CER2 0603 X7R 16V 1N PM10 R

2222 CER2 0603 X7R 50V 10N PM10 R

2225

223886715229

223878615649

223824659858

223878615649

223858615636

223858615623

202001293747

223886715339

223886715221

223878615649

223858615636

223858615636 CER2 0603 X7R 50V 10N PM10 R

2227

223858615636

CER2 0603 X7R 50V 10N PM10 R

2229

223858615636

CER2 0603 X7R 50V 10N PM10 R

2233

223878615649

CER2 0603 X7R 16V 1N PM10 R

2234

223878615649

CER2 0603 X7R 16V 1N PM10 R

3224 212211805643 RST SM 0603 RC0603 1R PM5R

3341 212211805669 RST SM 0603 RC0603 10K PM5R

3342 212211805643 RST SM 0603 RC0603 1R PM5R

3343 212211805643 RST SM 0603 RC0603 1R PM5R

3344 212211805643 RST SM 0603 RC0603 1R PM5R

3345 212211805643 RST SM 0603 RC0603 1R PM5R

3346 212211805643 RST SM 0603 RC0603 1R PM5R

3347 212211805643 RST SM 0603 RC0603 1R PM5R

3348 212211805643 RST SM 0603 RC0603 1R PM5R

3349 212211805678 RST SM 0603 RC0603 47K PM5R

3350 212211805669 RST SM 0603 RC0603 10K PM5R

3351 212211805669 RST SM 0603 RC0603 10K PM5R

3352 212211805669 RST SM 0603 RC0603 10K PM5R

3353 212211805669 RST SM 0603 RC0603 10K PM5R

3504 212211805643 RST

SM 0603 RC0603 1R PM5R

3505 212211805643 RST SM 0603 RC0603 1R PM5R

3506 212211805669 RST SM 0603 RC0603 10K PM5R

3507 212211805669 RST SM 0603 RC0603 10K PM5R

3508 212211805647 RST SM 0603 RC0603 220R PM5R

3509 212211805647 RST SM 0603 RC0603 220R PM5R

3510 212211805643 RST SM 0603 RC0603 1R PM5R

3512 212211805678 RST SM 0603 RC0603 47K PM5R

3527 212211805669 RST SM 0603 RC0603 10K PM5R

3528 212211805669 RST SM 0603 RC0603 10K PM5R

3532 212211805669 RST SM 0603 RC0603 10K PM5R

3533 212211805669 RST SM 0603 RC0603 10K PM5R

3537 212211805678 RST SM 0603 RC0603 47K PM5R

3302 212211805669 RST SM 0603 RC0603 10K PM5R

3303 212211805669 RST SM 0603 RC0603 10K PM

3304 212211805669 RST SM 0603 RC0603 10K PM5R

3305 212211805669 RST SM 0603 RC0603 10K PM5R

3306 212211805665 RST SM 0603 RC0603 4K7 PM5R

3307 212211805665 RST SM 0603 RC0603 4K7 PM5R

3308 212211805643 RST SM 0603 RC0603 1R PM5R

3309 212211805643 RST SM 0603 RC0603 1R PM5R

3311 212211805669 RST SM 0603 RC0603 10K PM5R

3312 212211805669 RST SM 0603 RC0603 10K PM5R

3314 212211805669 RST SM 0603 RC0603 10K PM5R

3320 232270462009 RST SM 0603 RC22H 20R PM1R

3321 212211805689 RST SM 0603 RC0603 1MPM5R

3322 212211805631 RST SM 0603 JUMP. MAX 0R05 R

3323 212211805665 RST SM 0603 RC0603 4K7 PM5R

3324 212211805665 RST SM 0603 RC0603 4K7 PM5R

3325 212211805665 RST SM 0603 RC0603 4K7 PM5R

3326 212211805665 RST SM 0603 RC0603 4K7 PM5R

3327 212211805643 RST SM 0603 RC0603 1R PM

3328 212211805643 RST SM 0603 RC0603 1R PM5R

3329 212211805643 RST SM 0603 RC0603 1R PM5R

3330 212211805643 RST SM 0603 RC0603 1R PM5R

3331 212211805631 RST SM 0603 JUMP. MAX 0R05 R

3332 212211805643 RST SM 0603 RC0603 1R PM5R

3333 212211805631 RST SM 0603 JUMP. MAX 0R05 R

3334 212211805643 RST SM 0603 RC0603 1R PM5R

3335 212211805643 RST SM 0603 RC0603 1R PM5R

3336 212211805643 RST SM 0603 RC0603 1R PM5R

3337 212211805643 RST SM 0603 RC0603 1R PM5R

3338 212211805643 RST SM 0603 RC0603 1R PM5R

3339 212211805643 RST SM 0603 RC0603 1R PM5R

3201 212211805669 RST SM 0603 RC0603 10K PM5R

3216 212211805643 R

ST SM 0603 RC0603 1R PM5R

3217 212211805643 RST SM 0603 RC0603 1R PM5R

3221 212211805674 RST SM 0603 RC0603 22K PM5R

3222 212211805674 RST SM 0603 RC0603 22K PM5R

3223 212211805643 RST SM 0603 RC0603 1R PM5R

3225 212211805643 RST SM 0603 RC0603 1R PM5R

3226 212211805643 RST SM 0603 RC0603 1R PM5R

3227 212211805661 RST SM 0603 RC0603 2K2 PM5R

3228 212211805661 RST SM 0603 RC0603 2K2 PM5R

3229 212211805678 RST SM 0603 RC0603 47K PM5R

3230 212211805674 RST SM 0603 RC0603 22K PM5R

3231 212211805635 RST SM 0603 RC0603 10R PM5R

3232 212211805643 RST SM 0603 RC0603 1R PM5R

3233 232273467509 RST SM 0805 RC12H 75R PM1R

3234 212211805638 RST SM

0603 RC0603 33R PM5R

3235 232273467509 RST SM 0805 RC12H 75R PM1R

3236 212211805643 RST SM 0603 RC0603 1R PM5R

3237 232273467509 RST SM 0805 RC12H 75R PM1R

3238 212211805665 RST SM 0603 RC0603 4K7 PM5R

3239 212211805669 RST SM 0603 RC0603 10K PM5R

3241 212211805669 RST SM 0603 RC0603 10K PM5R

3242 212211805656 RST SM 0603 RC0603 1K PM5R

3243 212211805631 RST SM 0603 JUMP. MAX 0R05 R

3244 212211805631 RST SM 0603 JUMP. MAX 0R05 R

3245 212211805631 RST SM 0603 JUMP. MAX 0R05 R

3401 212211805644 RST SM 0603 RC0603 120R PM5R

3402 212211805644 RST SM 0603 RC0603 120R PM5R

3403 212211805644 RS

T SM 0603 RC0603 120R PM5R

3404 212211805643 RST SM 0603 RC0603 1R PM5R

3405 212211805643 RST SM 0603 RC0603 1R PM5R

3409 212211805639 RST SM 0603 RC0603 47R PM5R

3410 212211805689 RST SM 0603 RC0603 1MPM5R

0615 313811707251 HEX CODE OF F/W

0291 313815564121 LABEL

0295 313815564121 LABEL
